Rescue Rigs
Lexington Fire Department Rescue 1
Checkout the pictures of the new Rescue 1 for the Lexington Fire Department in Kentucky. This rescue is a walk-in rescue tandem axle with a stainless steel body mounted on an E-ONE Cyclone 2-door custom cab.
Lexington Fire Department Rescue 1
Below are the pictures of the new Rescue 1 for the Lexington Fire Department in Kentucky. This rescue is a walk-in rescue tandem axle with a stainless steel body mounted on an E-ONE Cyclone 2-door custom cab.
Overview
Compartments
Front Bumper
Rear Compartments
Dimensions:
- Length: 38′-5″ (5″ bigger then current Rescue)
- Height: 10′-3″
- Interior Box Height: 76″
- Width: Cab-96″, Box-100″
- 7 occupants seating capacity
Features:
- 25-foot, 6-inch stainless steel walk-in rescue with interior height of 76 inches and 40-inch walkway
- Total seating capacity of 7 occupants
- 24-inch bumper extension
- Cummins ISX15 550-hp engine with EVS 4500 transmission
- Onan 30-kW PTO single-phase 120/240-volt generator
- 11 wheel well SCBA bottle storage with hinged S/S doors
- Command Light CL602A with six (6) FRC Spectra 220 watt LED heads
- Safety Vision backup, officer side external camera with internal crew cameras with monitor
Drawing
Strut Mounting
A company called Poly-Tech America® makes mounting solutions for Paratech brand struts. Their patent pending Snap-Lock Strut Mounting System™ has been designed to help organize, install and protect your Paratech struts and accessories. The space saving design optimizes apparatus compartment area.
First Due Fabrication LLC
Check out what First Due Fabrication LLC created to get 8 struts in a compartment that’s really only wide enough for 4. First Due Fabrication LLC double stacked the struts 2 rows deep using polytechamerica mounts. The outer row swing down out of the way allowing access to the inner set.
Below is are Poly-Tech America, LLC strut mounts and polyboxes on Cheshire Connecticut’s Rescue 1.
Lower St Croix Valley Rescue
Spartan Chassis, Stainless Bolted Body, Waterous 1500gpm Midship Pump, Waterous ADVANTUS Foam System, 750-Gallon Water Tank, Front Bumper Extension with Hose Reel, Adjustable Shelving, Pull-Out Compartment Trays, Pull-Out Tool Boards, Slide-In Ladder Storage, Swing-Out and Down Rear Ladder, Roll-Up Hosebed Cover
Below are links to more information about this heavy rescue:
- Production Specification
- Features (Flyer)
- CAD Drawing
Overall Pictures
Compartments Pictures
Cab Pictures
Rooftop Pictures
Bumper Pictures
Rear
Rescue Rigs
First Look: Cincinnati Fire Department Heavy Rescue
First Look at a new Cincinnati Fire Department Heavy Rescue
Heavy Rescue
Specification Options
- Body: EXT
- Engine: Cummins
- Chassis: RBM Commander
- Horsepower: 500
- Axles: Tandem
- Generator: Onan 20KW
