Vehicle Extrication

2016 Tesla Model X Falcon Wing Doors

Tesla Motors is committed to helping fire departments and first responders safely handle emergency situations involving their vehicles by providing Emergency Response Guides.

Published

on

Tesla Model X

Tesla Motors is committed to helping fire departments and first responders safely handle emergency situations involving their vehicles by providing Emergency Response Guides. Emergency disconnects are available for disabling the vehicle when extrication is necessary to rescue passengers.  Below are a few screen shots from their Model X First Responder Guide that highlight the falcon door. The springs that open the door and the stored gas inflators are the only features that responders need to understand and know the location of each. Brock Archer, Owner of Advanced Extrication has worked closely with Tesla and helped their first responder material.  Brock wrote the Model X First Responder Guide and a video to follow up with the guide should be out soon.
Make sure you check out his website AdvancedExtrication.com
[email protected]

Tesla-Model-X-Falcon-Door-Extrication-Rescue-Latch-Release-Power Tesla-Model-X-Falcon-Door-Extrication-Rescue-Latch-Release Tesla-Model-X-Falcon-Door-Extrication-Rescue-Latch

Warning: Never cut the high tension springs attached to the falcon wing doors. Serious injury or death can result from cutting or rapidly releasing the high tension springs.
Tesla-Model-X-Falcon-Door-Extrication-Rescue

The Airbag inflation cylinders are located in the A-pillars and in the falcon wing doors, as outlined in red below.

Tesla-Model-X-Falcon-Door-Extrication-Air-Inflator-Airbag-Stored-Gas

Tesla-Model-X-Falcon-Door-Extrication-Air-Inflator-Airbag-Stored

Quick Note

Like most electric and hybrid vehicles, Tesla vehicles are electric and make no noise even when the power-train is energized.

Mike Smith, Absolute Rescue's Editor in Chief, is a veteran of the fire/rescue service in Michigan, who also works in the automotive industry as a designer. Have an idea of suggestion for the site? Contact Mike here

School Bus

HydroFusion Ram

HydraFusion Struts used as ram for a dash roll?

Published

on

HydraFusion Strut Ram

The HydraFusion Struts were a game changer when PARATECH released the lifting/stabilizing device a few years back at FDIC. Rescuers can lift up to 10 U.S. Tons (9 metric tons) and to stabilize up to 20,000 lbs. with the tool. However, PARATECH’s HydraFusion Struts are not limited to just those two functions. The HydraFusion Struts can move metal!

I first ran across pictures of HydraFusion Struts used as ram from pictures that Brock Archer (Advanced Extrication) and Randy Schmitz ( Founder/Owner of Schmitz Mittz). Last weekend at Crunchtime Extrication, Paratech had one of their trailers at the training event and I had the chance to try a dash roll with a HydraFusion Strut. Take a look at the video below.

A few quick points:

  • You can put the HydraFusion Strut in place to reduce any dash movement during reliefs cuts.
  • HydraFusion Strut are portable and can be moved quickly to a vehicle hundreds of feet of the roadway.
  • Depending on the length of the HydraFusion Strut used, strut extensions can be used to optimize dash movement.
  • Using a HydraFusion Strut as a ram is an option, not always the option.
Below  are a few pictures from the Advanced Heavy Rescue Symposium in Calgary, Alberta, that show HydraFusion Struts used a ram during bus extrication to displace a roof.

This slideshow requires JavaScript.

Continue Reading

Heavy Rescue

ALBERTA Advanced Heavy Rescue Symposium

Published

on

Sept 22-23, 2017 Advanced Heavy Rescue Symposium at the CFD Training Academy registration forms ready to be sent out, email me if your interested. Only 60 spots available.





Continue Reading

Training

No Laminated Side Glass in a 2017 Vehicle?

I was sent a message from a firefighter the other night asking about a 2017 vehicle that he found did not have side laminated windows? This firefighter was up-to-date on his knowledge about the FMVSS 226 occupant ejection mitigation requiring laminated side glass in all 2017 vehicles. But how can a 2017 model vehicle have tempered

Published

on

Laminated Side Glass

NissanI was sent a message from a firefighter the other night asking about a 2017 vehicle that he found did not have side laminated windows? This firefighter was up-to-date on his knowledge about the FMVSS 226 occupant ejection mitigation and laminated side glass. However, the laminated glass is meant more as a supplement to side curtain airbags. The curtains will be made larger so that they cover more of the window opening, made more robust to remain inflated longer, and made to deploy in both side impacts and in rollovers. So that is one reason why a 2017 model vehicle have tempered and not laminated glass.  What is a another? Phase-in periods and credits, that’s how. Let me explain.

The FMVSS 226 phase-in period started on September 1, 2013 and ends September 1, 2017 when all automobiles manufactured must meet the new standard. So, the way vehicle models run, the 2018 models will start hitting dealer floors in the summer of 2017. That means some 2018 models may not meet the standard if those vehicles are made before to September 1, 2017. Confused yet? It gets worse!

Automakers can earn credits for vehicles that do not meet the standard starting with automobiles made from March 1, 2011 and ending at the conclusion of the phase-in, September 1, 2017. So what does that mean? If an automaker made enough vehicles ahead of the September 1, 2017 date, they could sell that number of vehicles into 2017, 2018, and maybe even into 2019 that do not meet the standard. Automakers may use this to extend product of a vehicle that they intend to stop selling or delay developing a new model that meets the standard.

The bottom line is look for larger curtain airbags that stay inflated longer supplemented with laminated or glazed glass. Hope that helps!

Continue Reading
